Fitting the handle
Screw in the left grip to the bracket provided on the
frame and tighten securely.
Fitting the aug
er
Slide the ring clip (A) and remove the locking pin (B)
from the auger.
Fit the auger (C) to the output shaft (D).
Fit the locking pin and slide the ring clip so that it
covers the locking pin.
A
A
B
C
D
