PRIME/PRO/TUF GAMING X570 Series BIOS Manual

Q-fan Conguration

Q-fan Tuning

Click this item to automatically detect the lowest speed and congure the minimum

duty cycle for each fan.

CPU Q-Fan Control

This item allows you to set the CPU Q-Fan operating mode.

[Auto] Detects the type of CPU fan installed and automatically switches

the control modes.

[PWM Mode] Enables the CPU Q-Fan Control feature in PWM mode for 4-pin

CPU fan.

[DC Mode] Enables the CPU Q-Fan Control feature in DC mode for 3-pin CPU

fan.

[Disabled] Disables the Q-Fan Control.

The following items appear only when you set the CPU Q-Fan Control to [Auto], [PWM

Mode], and [DC Mode].

CPU Fan Step Up/Down

This item allows you to set the value of the CPU fan step up/down.

Conguration options: [0 sec] [2.1 sec] [2.8 sec] [3.6 sec] [4.2 sec] [5.0 sec] [6.3 sec]

[8.5 sec] [12 sec] [25 sec]

CPU Fan Speed Lower Limit

This item allows you to set the low limit warning for CPU Fan speed.

Conguration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]

CPU Fan Profile

This item allows you to set the appropriate performance level of the CPU fan.

[Standard] Set to make the CPU fan adjust automatically depending on the CPU

temperature.

[Silent] Set to minimize the fan speed for quiet CPU fan operation.

[Turbo] Set to achieve maximum CPU fan speed.

[Manual] Set to assign the detailed fan speed control parameters.

The following items appear only when you set the CPU Fan Prole to [Manual].

CPU Upper Temperature

Use the <+> and <-> keys to adjust the upper limit of the CPU temperature.

The CPU fan will operate at the maximum duty cycle when the CPU

temperature is higher than the limit.
