PCIe bifurcation & M.2 settings in PCIe x16 slots with AMD Ryzen™ 5000

Series / 3000 Series Desktop Processors

Slot Description

Quantity of identifiable M.2 SSD (pcs)

Situation 1 Situation 2

1. PCIe 4.0 x16_1 4 (x4+x4+x4+x4) 2 (x4+x4)

2. PCIe 4.0 x16_2 - 2 (x4+x4)

3. PCIe 3.0 x16_3 1 (x4) 1 (x4)

PCIe bifurcation & M.2 settings in PCIe x16 slots with AMD Ryzen™ 3000

G-Series / 2000 G-Series Processors

Slot Description

Quantity of identifiable M.2 SSD (pcs)

Situation 1

1. PCIe 3.0 x16_1 2 (x4+x4)

2. PCIe 3.0 x16_2 -

3. PCIe 3.0 x16_3 1 (x4)

PCIe bifurcation & M.2 settings in PCIe x16 slots with AMD Ryzen™ 5000

G-Series / 4000 G-Series Processors

Slot Description

Quantity of identifiable M.2 SSD (pcs)

Situation 1 Situation 2

1. PCIe 3.0 x16_1 3 (x8+x4+x4) 1 (x8)

2. PCIe 3.0 x16_2 - 2 (x4+x4)

3. PCIe 3.0 x16_3 1 (x4) 1 (x4)

• Hyper M.2 X16 series card sold separately.

• Enable the Hyper M.2 X16 series card under BIOS settings.
