Asus ProArt X570-CREATOR WIFI [41/80] Chapter 2

ProArt X570-CREATOR WIFI

2-3

Chapter 2

CPU heatsink and fan assembly Type 2

When using this type of CPU fan, remove the screws and the retention module only. Do

not remove the plate on the bottom.
