Asus ROG Zenith II Extreme Alpha [23/112] Expansion slots

ROG ZENITH II EXTREME ALPHA

1-7

Chapter 1

1.5 Expansion slots

Unplug the power cord before adding or removing expansion cards. Failure to do so may

cause you physical injury and damage motherboard components.
