English
7
B760M PG Riptide
No. Description
1 ATX 12V Power Connector (ATX12V2)
2 ATX 12V Power Connector (ATX12V1)
3 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
4 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
5 CPU Fan Connector (CPU_FAN1)
6 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
7 Addressable LED Header (ADDR_LED3)
8 Addressable LED Header (ADDR_LED2)
9 ATX Power Connector (ATXPWR1)
10 USB 3.2 Gen1 Header (USB3_5_6)
11 Front Panel Type C USB 3.2 Gen1 Header (F_USB3_TC_1)
12 SATA3 Connectors (SATA3_2)(Upper), (SATA3_3)(Lower)
13 System Panel Header (PANEL1)
14 SATA3 Connector (SATA3_1)
15 SATA3 Connector (SATA3_0)
16 SPI TPM Header (SPI_TPM_J1)
17 Post Status Checker (PSC)
18 USB 2.0 Header (USB_5_6)
19 Chassis Intrusion and Speaker Header (SPK_CI1)
20 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
21 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
22 Clear CMOS Jumper (CLRMOS1)
23 Addressable LED Header (ADDR_LED1)
24 RGB LED Header (RGB_LED1)
25 Front Panel Audio Header (HD_AUDIO1)
26 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
