ASRock B760M PG Riptide [7/53] Storage
![ASRock B760M PG Riptide [7/53] Storage](/views2/1921005/page7/bg7.png)
English
3
B760M PG Riptide
•
1 x DisplayPort 1.4 with DSC (compressed), supports HDCP
2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
•
Nahimic Audio
LAN
•
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
•
Dragon RTL8125BG
•
Supports Phantom Gaming LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
USB
•
2 x USB 3.2 Gen1 Type-C (1 Rear, 1 Front)
•
5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
•
6 x USB 2.0 (4 Rear, 2 Front)
* All USB ports support ESD Protection
Rear Panel
I/O
•
2 x Antenna Mounting Points
•
1 x PS/2 Mouse/Keyboard Port
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen1 Type-C Port
•
3 x USB 3.2 Gen1 Type-A Ports
•
4 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
CPU:
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
•
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
•
4 x SATA3 6.0 Gb/s Connectors
