ASRock B760M Pro RS/D4 [3/61] Chapter 1 introduction 1
![ASRock B760M Pro RS/D4 [3/61] Chapter 1 introduction 1](/views2/1921010/page3/bg3.png)
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 6
1.4 I/O Panel 9
1.5 Block Diagram 12
1.6 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz
Antennas (For B760M Pro RS/D4 WiFi) 13
Chapter 2 Installation 15
2.1 Installing the CPU 16
2.2 Installing the CPU Fan and Heatsink 18
2.3 Installing Memory Modules (DIMM)
19
2.4 Connecting the Front Panel Header 21
2.5 Installing the Motherboard 22
2.6 Installing SATA Drives 23
2.7 Installing a Graphics Card 25
2.8 Connecting Peripheral Devices 27
2.9 Connecting the Power Connectors 28
2.10 Power On 29
2.11 Jumpers Setup 30
2.12 Onboard Headers and Connectors 31
2.13 Post Status Checker 43
