B760M Pro RS/D4 WiFi
B760M Pro RS/D4
Chapter 1 Introduction
ank you for purchasing ASRock B760M Pro RS/D4 WiFi / B760M Pro RS/
D4 motherboard, a reliable motherboard produced under ASRock’s consistently
stringent quality control. It delivers excellent performance with robust design
conforming to ASRock’s commitment to quality and endurance.
1.1 Package Contents
•
ASRock B760M Pro RS/D4 WiFi / B760M Pro RS/D4 Motherboard (Micro ATX Form
Factor)
•
ASRock B760M Pro RS/D4 WiFi / B760M Pro RS/D4 User Manual
•
2 x Serial ATA (SATA) Data Cables (Optional)
•
2 x ASRock WiFi 2.4/5/6 GHz Antennas (Optional) (For B760M Pro RS/D4 WiFi)
•
2 x Screws for M.2 Sockets (Optional) (For B760M Pro RS/D4 WiFi)
•
3 x Screws for M.2 Sockets (Optional) (For B760M Pro RS/D4)
•
1 x Stando for M.2 Socket (Optional)
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any modi-
cations of this documentation occur, the updated version will be available on ASRock’s
website without further notice. If you require technical support related to this mother-
board, please visit our website for specic information about the model you are using. You
may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com.
