ASRock B760M Pro RS/D4 [8/61] Connector
![ASRock B760M Pro RS/D4 WiFi [8/61] Connector](/views2/1921010/page8/bg8.png)
4
USB
•
2 x USB 3.2 Gen1 Type-C (1 Rear, 1 Front)
•
5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
•
6 x USB 2.0 (2 Rear, 4 Front)
* All USB ports support ESD Protection
Rear Panel
I/O
•
2 x Antenna Ports (For B760M Pro RS/D4 WiFi)
•
2 x Antenna Mounting Points (For B760M Pro RS/D4)
•
1 x PS/2 Mouse/Keyboard Port
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen1 Type-C Port
•
3 x USB 3.2 Gen1 Type-A Ports
•
2 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
CPU:
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type
2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
•
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
•
4 x SATA3 6.0 Gb/s Connectors
* Supports Intel® Volume Management Device (VMD)
* Supports NVMe SSD as boot disks
RAID
•
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Connector
•
1 x SPI TPM Header
•
1 x Chassis Intrusion and Speaker Header
•
1 x RGB LED Header*
•
3 x Addressable LED Headers**
•
1 x CPU Fan Connector (4-pin)***
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)****
•
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)*****
