LG GR-M602YLQ [19/72] Starting

LG GR-M602YLQ [19/72] Starting
CONTROLS FOR REFRIGERATOR COMPARTMENT
The default setting of the temperature control button for
the refrigerator compartment is NORMAL.
To control the refrigerator temperature, press the REF.
TEMP CONTROLbutton.
When the button is pressed, the LEDs light.
The temperature is set in 5 steps, from MIN to MAX.
OPERATIONS
18
STARTING
When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures
prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
REF. TEMP. CONTROL
MIN MAX
CONTROLS FOR FREEZER COMPARTMENT
The higher number the control setting is, the lower the
temperature of the freezer compartment becomes.
Since the temperature of the refrigerator and freezer compartments is controlled with a fixed amount of
cooled air, compartment becomes colder.the refrigerator compartment will be warmer if the freezer
When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High(4~7).
Setting the Freezer Knob at will satisfy 4 STAR. Setting the Freezer Knob at NORMAL will have
sufficient freezing effect, so it is recommended to set the Knob at NORMAL.
1
7
3
24 3
FREEZER CONTROL
FREEZER MIN
NORMAL
FREEZER MAX
Ref. Temp Control Button
Model : GR-B628***/B528***
1
8
3
24 3
FREEZER CONTROL
FREEZER MIN
NORMAL
FREEZER MAX
Model : GR-B492***

Содержание

OPERATIONS STARTING When your refrigerator is first installed allow it 2 3 hours to stabilize at normal operating temperatures prior to tilling it with fresh or frozen foods It operation is interrupted wait 5 minutes before restarting CONTROLS FOR REFRIGERATOR COMPARTMENT The default setting of the temperature control button for the refrigerator compartment is NORMAL To control the refrigerator temperature press the REF TEMP CONTROLbutton When the button is pressed the LEDs light The temperature is set in 5 steps from MIN to MAX Ref Temp Control Button CONTROLS FOR FREEZER COMPARTMENT The higher number the control setting is the lower the temperature of the freezer compartment becomes Since the temperature of the refrigerator and freezer compartments is controlled with a fixed amount of cooled air the refrigerator compartment will be warmer it the freezer compartment becomes colder When the freezer compartment is not cold enough in winter adjust the control for the freezer to High 4 7 Setting the Freezer Knob at 000 will satisfy 4 STAR Setting the Freezer Knob at NORMAL will have sufficient freezing effect so it is recommended to set the Knob at NORMAL Model GR B628 B528 Model GR B492 18
