HT-435R
Operation Manual
ENG
5.1 Active Home Theater
Speaker System
27
7. TECHNICAL SPECIFICATIONS
Notes. The above specifications are only for reference. Technical specifications and package
contents are subject to change without notice due to the improvement of SVEN production. Durability —
5 years. Technical support is on www.sven.fi.
Parameter, measurement unit
Output power (RMS), W:
Speaker diameters, mm:
subwoofer
front, rear satellites
center satellite
Supply voltage, V/Hz
Frequency range, Hz:
subwoofer
satellites
Dimensions (one speaker), mm:
subwoofer
front, rear satellites
center satellite
Weight, kg
Value
110 (35 + 5 × 15)
= 165
full range = 76
full range 2 × = 76
AC 220/50
40 – 150
150 – 20 000
313 × 170 × 313
95 × 110 × 120
95 × 220 × 110
8.5
6. TROUBLESHOOTING
Problem
No power.
No sound.
Subwoofer no
sound or volume
low.
Distortion.
The remote control
malfunctions.
Cause
The power plug connected improperly.
The power switch doesn’t turn on.
The volume regulator is at minimum position.
The signal source is connected improperly.
Wrong choice for signal in selector.
The mute button on the remote control
is activated.
The signal source improper connection.
The subwoofer volume regulator is at minimum
position.
Volume is too loud.
The RC receiving window on the panel is hidden
or don’t face the receiving window.
Solution
Reconnect properly.
Turn on the power switch.
Turn the volume regulator properly.
Connect properly.
Choose signal source correctly.
Press mute button on the RC or volume
control button once.
Connect the signal source properly.
Adjust the subwoofer regulator
properly.
Adjust the volume regulator properly.
Please remove the barrier or let the
RC face receiving window.
If none of the above methods can not solve the problem, please seek professional advice at your nearest ser-
vice center. Never attempt to repair the product yourself.
