GA-EX58-UD3R Motherboard - 10 -
1-2 Product Specifications
CPU Support for an Intel
®
Core
TM
i7 series processor in the LGA 1366 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
QPI 4.8GT/s, 6.4GT/s
Chipset North Bridge: Intel
®
X58 Express Chipset
South Bridge: Intel
®
ICH10R
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual/3 channel memory architecture
Support for DDR3 2000/1333/1066/800 MHz
memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio Realtek ALC888 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF In/Out
Support for CD In
LAN 1 x Realtek 8111D chip (10/100/1000 Mbit)
Expansion Slots 2 x PCI Express x16 slots, running at x16
(The PCI Express slots support ATI CrossFireX
TM
technology and conform
to PCI Express 2.0 standard.)
1 x PCI Express x4 slot
2 x PCI Express x1 slots
2 x PCI slots
Storage Interface South Bridge:
- 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2
SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1 and JBOD
iTE IT8720 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB Integrated in the South Bridge
Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
IEEE 1394 T.I. TSB43AB23 chip
Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a
bracket connected to the internal IEEE 1394a header)
