- 43 - BIOS Setup
>>>>> Channel A/B/C Advanced Timing Control
tRC
Options are: Auto (default), 1~63.
tRRD
Options are: Auto (default), 1~15.
tWTR
Options are: Auto (default), 1~31.
tWR
Options are: Auto (default), 1~31.
tRFC
Options are: Auto (default), 1~255.
tRTP
Options are: Auto (default), 1~15.
tFAW
Options are: Auto (default), 1~63.
Command Rate(CMD)
Options are: Auto (default), 1~2.
>>>>> Channel A/B/C Misc Timing Control
Round Trip Latency
Options are: Auto (default), 1~255.
>>>>> Channel A/B/C Turnaround Settings
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
Channel A Turnaround Settings
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
>>>>> Channel A Writes Followed by Reads
x Different DIMMs 7 Auto
x Different Ranks 7 Auto
x On The Same Rank 4 Auto
>>>>> Channel A Reads Followed by Writes
x Different DIMMs 7 Auto
x Different Ranks 7 Auto
x On The Same Rank 7 Auto
>>>>> Channel A Reads Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 5 Auto
x On The Same Rank 1 Auto
>>>>> Channel A Writes Followed by Writes
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 1 Auto
Item Help
Menu Level
>>>>> Channel A/B/C Writes Followed by Reads
Different DIMMs
Options are: Auto (default), 1~8.
