LG V-K8701HTU [16/18] Replacement parts list
![LG V-K8701HTU [16/18] Replacement parts list](/views2/1094967/page16/bg10.png)
-16-
REPLACEMENT PARTS LIST
R : SERVICE PARTS
*01 MFL32342001 Manual,Owners R
*10 MAY34246901 Box R
ABCAD1 5203FI1216C Brush Assembly R
ACQCE1 3551FI2451D Cover Assembly,Exhaust R
ACVCA1 4901FI2001Y Damper Assembly R
ADQBE1 5231FI2472D Filter Assembly,Exhaust R
ADVTF1 3211FI1005B Frame Assembly,Filter R
AEMAF1 5215FI1364T Hose Assembly,Flexible R
AGBN47 5249FI1437A Nozzle Assembly,Turbine R
AGBN50 5249FI1445K Nozzle Assembly,Floor R
AGRPT1 5201FI2508J Pipe Assembly,Telescopic R
AHDBR1 4687FI1501C Reel Assembly R
AHJBA1 4441FI3621A Roller Assembly R
AJLTD1 4839FI1053J Tank Assembly,Dust R
AJWBA1 4661FI2424E Wheel Assembly R
EADCS1 6631FI3155E Harness,Single R
EAUBA1 4681FI2467D Motor Assembly,AC,Vacuum Cleaner R
EBFCZ1 6601FI3501C Switch,Pressure R
EBRBM1 6871FX2216L PCB Assembly,Main R
EBRCD1 6871FX2237B PCB Assembly,Display R
MAMBB1 3040FI1567A Base,Body R
MBGBR1 5020FI3845C Button,Cord Reel R
MBLTD1 MBL32968001 Cap,Dust R
MCKBC1 3550FI2670A Cover,Housing R
MCKBD8 3550FI2668A Cover,Decor R
MCKBD9 3550FI2669A Cover,Decor R
MCKBE1 3550FI2667A Cover,Exhaust Filter R
MCKBE8 3550FI2674A Cover,Exhaust Filter R
MCKCB1 3550FI1937A Cover,Body R
MCKCD1 3550FI3963B Cover,Decor R
MCKCD8 3550FI2672A Cover,Decor R
MCKCD9 3550FI2671A Cover,Decor R
MCKCP1 3550FI3962A Cover,Display R
MCKCR8 MCK30372801 Cover,Rear R
MCKCR9 MCK30372401 Cover,Rear R
MCKCT1 3550FI1938A Cover,Top R
MCKCZ1 3550FI3802D Cover,Terminal R
MCKTD1 3550FI2673B Cover,Decor R
MCKTS1 3550FI1939A Cover,Dust R
LOC. NO. PART NO. DESCRIPTION
SVC
REMARK
