Learn a key

If you miss certain functions from your original remote control of the

SRU 5060, the SRU 5060 can learn these functions from the original remote

control.You can store a fuction under any of the available keys of the

SRU 5060, except LEARN, SELECT and SHIFT. Please, note that any function

already stored under a key will be deleted.

Example for VCR:

Make sure you have the original VCR remote control at hand.

1 Select the device mode VCR, with the

SELECT key.

2 Press the LEARN key and the target key on

the SRU 5060 simultaneously for 5 seconds,

until VCR in the selector window blinks twice

and then remains lit.

3 Place both remote controls on a flat surface

(like a coffee table) and aim them head-to-

head with about 5 - 10 cm in between.

4 Press the button you want to copy on the original remote control.

– If the SRU 5060 has learned the code,VCR in the selector window

blinks twice to confirm the signal is stored.

– If VCR blinks once for a longer period, the IR signal is not learned by the

SRU 5060. Please, try a few times and make sure the remote controls

are aligned as described in step 3.

If the SRU 5060 cannot learn the code after several times trying,

it is possible that:

– The IR signal of your original device is out of range (the SRU 5060 can

only learn IR signals with a carrier signal of 30-60kHz.

– The memory of the SRU 5060 is full.

– The SRU 5060 stopped the learning process after 20 seconds if no

IR signals are found. Check if your original remote control is working

correctly.

Restoring the original functions of your remote

control

1 Keep keys 1 and 6 on the SRU 5060

pressed simultaneously for three seconds,

until until one of the device indicators (TV,

DVD, STB,VCR, CD, AMP) lights up window.
