Zanussi ZXL 66 ITX [5/28] Instruction for the user

Once the hob has been installed, it is

important to remove any protective materials,

which were put on in the factory.

Hob burners control knobs

The hob burners control knobs are situated on the hob

right hand side. The symbols on the knobs mean that:

there is no gas supply

there is maximum gas supply

there is minimum gas supply

Lighting the burners

For easier lighting, proceed before putting a

pan on the pan support.

To light a burner, push in the relevant knob and

turn it anticlockwise to "maximum position".

After lighting the flame, keep the knob pushed

down for about 5 seconds. This will allow the

"thermocouple" (Fig. 1, lett. D) to be heated and

the safety device to be switched off, otherwise the

gas supply would be interrupted.

Then, check the flame is regular and adjust it as

required.

If you cannot light the flame even after several

attempts, check the "cap" (Fig. 1, lett. A) and the

"crown" (Fig. 1, lett. B) are in the correct position.

To put the flame out, turn the knob to the symbol .

• Always turn the flame down or put it out before

taking the pans off the burner.

Do not keep the control knob pressed for more

than 15 seconds.

If the burner does not light even after 15 seconds,

release the control knob, turn it the “off” position

and wait for at least one minute before trying to

light the burner again.

If the burner accidentally goes out, turn the control

knob to the “off” position and wait for at least 1

minute before trying to light the burner again.

Instruction for the User

Fig. 1

A- Burner cap

B- Burner crown

C- Ignition candle

D- Thermocouple

•
