Elenberg MG-2035D [21/27] Installation

Turntable installation

a. Never place the glass tray upside down. The glass tray

should never be restricted.

b. Both glass tray and turntable ring assembly must always be

used during cooking.

c. All food and containers of food should be always placed on

the glass tray for cooking.

d. The glass tray rotates clockwise; this is normal.

e. If glass tray or turntable ring assembly cracks or breaks, con-

tact your nearest authorized service

centre.

Remove all packing material and accessories. Examine the oven for any damage such as dents or

broken door. Do not install if oven is damaged.

Countertop

Cabinet: Remove any protective film found on the cabinet surface.

Do not remove the light brown oven cover that is screwed to the oven cavity to protect the

magnetron.

1. Select a level surface that provide enough open space for the intake and/or outlet vents.

A minimum clearance of 3.0 inch (7.5cm)

is required between the oven and any adja-

cent wall. One side must be open.

(1) Leave a minimum clearance of 12 inch

(30cm) above the oven.

(2) Do not remove the legs from the bottom of

the oven.

(3) Blocking the intake and/or outlet open-

ings can damage the oven.

(4) Place the oven as far away from radios and

TV as possible.Operation of microwave

oven may cause interference to your radio or TV reception.

2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the

same as the voltage and the frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-pro-

ducing appliance. If installed could be damaged and the warranty would

be void.

The accessible surface may be hot during operation.

Hub (underside)

Glass

tray

Turntable shaft

Turntable ring assembly

Installation

7,5 cm

30 cm

Open
