Hotpoint-Ariston H6TMH4AF (X) [11/44] Using the oven

Start-up and useStart-up and use

Using the hob

Lighting the burners

For each BURNER knob there is a complete ring showing

the strength of the flame for the relevant burner.

To light one of the burners on the hob:

1. Bring a flame or gas lighter close to the burner.

2. Press the BURNER knob and turn it in an anticlockwise

direction so that it is pointing to the maximum flame

setting (.

3. Adjust the intensity of the flame to the desired level by

turning the BURNER knob in an anticlockwise direction. This

may be the minimum setting &, the maximum setting ( or

any position in between the two.

If the appliance is fitted with an

electronic lighting device* (see

 gure), press the ignition button,

marked with the symbol



, then

hold the BURNER knob down

and turn it in an anticlockwise

direction, towards the maximum

flame setting, until the burner

is lit.The burner may be extinguished when the knob is

released. If this occurs, repeat the operation, holding the

knob down for a longer period of time.

! If the flame is accidentally extinguished, switch off the

burner and wait for at least 1 minute before attempting

to relight it.

If the appliance is equipped with a flame failure

safety device*, press and hold the BURNER knob for

approximately 2-3 seconds to keep the flame alight and

to activate the device.

To switch the burner off, turn the knob until it reaches

the stop position •.

Flame adjustment according to levels

the burner flame intensity can be adjusted with the

knob according to 6 power levels, from maximum

to minimum with 4 intermediate positions:

a click will indicate the change from one level to

another when turning the knob. The system

guarantees a more precise adjustment, allows

to replicate the flame intensity and to identify

easily the preferred level for different cooking

operations.

Practical advice on using the burners

For the burners to work in the most efficient way possible

and to save on the amount of gas consumed, it is

recommended that only pans that have a lid and a flat

base are used. They should also be suited to the size of

the burner:

To identify the type of burner, please refer to the diagrams

contained in the “Burner and nozzle specifications”.

! For models equipped with a reducer grid, the latter must

be used only for the auxiliary burner, when pans with a

diameter of less than 12 cm are used.

Using the oven

! The first time you use your appliance, heat the empty

oven with its door closed at its maximum temperature

for at least half an hour. Ensure that the room is well

ventilated before switching the oven off and opening the

oven door. The appliance may emit a slightly unpleasant

odour caused by protective substances used during the

manufacturing process burning away.

! Before operating the product, remove all plastic film

from the sides of the appliance.

! Never put objects directly on the bottom of the oven; this

will avoid the enamel coating being damaged.

1. Select the desired cooking mode by turning the

SELECTOR knob.

2. Select the recommended temperature for the

cooking mode or the desired temperature by turning the

THERMOSTAT knob.

A list detailing cooking modes and suggested cooking

temperatures can be found in the relevant table (see Oven

cooking advice table).

During cooking it is always possible to:

• Change the cooking mode by turning the SELECTOR

knob.

• Change the temperature by turning the THERMOSTAT

knob.

Burner Cookware Diameter (cm)

Fast (R) 24 - 26

Semi Fast (S) 16 - 20

Auxiliary (A) 10 - 14

Triple Crown (TC) 24 - 26
