![Indesit K 6C7 M.C_R [6/40] Using instructions the oven](/views2/1961231/page6/bg6.png)
6
Using instructions the oven
The various functions included in the cooker are selected
by operating the control devices located on the cooker
control panel.
Notice: The first time you use your appliance, we recom-
mend that you set the thermostat to the highest setting
and leave the oven on for about half an hour with nothing
in it, with the oven door shut. Then, open the oven door
and let the room air. The odour that is often detected dur-
ing this initial use is due to the evaporation of substances
used to protect the oven during storage and until it is in-
stalled.
Attention: Only use the bottom shelf of the oven when
using the rotisserie to cook (where present). For all other
types of cooking, never use the bottom shelf and never
place anything on the bottom of the oven when it is in
operation because this could damage the enamel. Always
place your cookware (dishes, aluminium foil, etc. etc.) on
the grate provided with the appliance inserted especially
along the oven guides.
Attention: to use the oven in manual mode without the
cooking control timer, match the indicator on the control
panel with the
symbol on the timer knob.
The Oven Control Knobs
The multifunction oven combines the advantages of tradi-
tional convection ovens with those of the more modern
forced air ventilation models. It is an extremely versatile
appliance that allows you to easily and safely choose be-
tween 5 different cooking modes. The various features
are selected by means of the knobs located on the con-
trol panel:
G - selector knob;
H - thermostat knob.
When the selector knob is on any other setting than that
identified by the “o”, the oven light turns on. The setting
identified by the
symbol makes it possible to turn the
oven light on without having any of the oven heating ele-
ments on. When the oven light is on, it means that the
oven is in use, and it will remain on for the entire time the
oven is being used.
1.Convection Mode
- Position of the “G” knob:
- Position of the “H” knob: between 50°C and Max
On this setting, the light comes on and the top and bottom
heating elements are activated. This is the classic, tradi-
tional type oven which Ariston has perfected, with excep-
tional heat distribution and reduced energy consumption.
The convection oven is still unequalled when it comes to
cooking dishes made up of several ingredients, e.g. cab-
bage with ribs, stews, etc. Excellent results are achieved
when preparing meat-based dishes as well (braised meats,
stew, goulash, wild game, ham etc.) which need to cook
slowly and require basting or the addition of liquid. It still
remains the best system for cooking pastries and fruit in
general. When cooking in convection mode, only use one
dripping-pan or cooking rack at a time, otherwise the heat
distribution will be uneven. Select from among the various
rack heights based on whether the dish needs more or
less heat from the top or bottom.
2. Ventilation Mode
- Position of the “G” knob:
- Position of the “H” knob: between 50°C and Max
Since the heat remains constant and uniform throughout
the oven due to the fan at the bottom, the air cooks and
browns food uniformly over its entire surface. With this
mode, you can also cook various dishes at the same time,
as long as their respective cooking temperatures are the
same.
A maximum of 2 rack levels can be used at the
same time, following the instructions in the section enti-
tled, "Cooking On More Than One Rack". This cooking
mode is ideal for au gratin dishes or those which require
an extended cooking time like lasagne etc...
Moreover, the excellent heat distribution makes it possi-
ble to use lower temperatures when cooking roasts. This
results in less loss of juices, meat which is more tender
and a decrease in the loss of weight for the roast. The
ventilated mode is especially suited for cooking fish, which
can be prepared with the addition of a limited amount of
condiments, thus maintaining their flavour and appear-
ance. Excellent results can also be attained when cook-
ing vegetable-based side dishes like cabbage, beats, cour-
gettes, aubergines, peppers, etc.
Desserts: leavened cakes are also perfect for the venti-
lated mode. Moreover, this mode can also be used to thaw
white or red meat, fish and bread by setting the tempera-
ture to 80°-100°C. To thaw more delicate foods, set the
thermostat to 50°C or use only the cold air circulation fea-
ture by setting the thermostat to 0°C.
3. Grill
- Position of the “G” knob:
- Position of the “H” knob: Max
The incandescent heating element cooks food by means
of thermal radiation directed downward. The extremely high
and direct temperature of the grill makes it possible to
brown the surface of meats and roasts while locking in
the juices to keep them tender. The grill is also highly rec-
ommended for dishes that require high temperature on
the surface: beef steaks, veal, entrecôte, filets, hamburger
etc...
4. Double Grill
- Position of the “G” knob:
- Position of the “H” knob: Max
This oversized grill has a completely new design, increas-
ing cooking efficiency by 50%. The double grill also elimi-
nates pockets of unheated air in the corners of the oven.
Note: When using the grill (features 3, 4), the oven door
must be closed.
5. Ventilated Double Grill
- Position of the “G” knob:
- Position of the “H” knob: between 50 and 200°C
This combination of features increases the effectiveness
of the unidirectional thermal radiation of the heating ele-
ments through forced air circulation of the air throughout
the oven. This helps prevents foods from burning on the
surface, allowing the heat to penetrate into the food. Ex-
