ENGLISH

Preparing for use

Assembling the juicing unit

1 Attach the pulp outlet to the juicing unit and turn it clockwise until the arrow

(

) points to the ‘locked’ indication. (Fig. 2)

2 Insert the black juicing screw into the juicing unit (Fig. 3).

Note: The juicing screw is not suitable for preparing sorbet, and the sorbet screw

is not suitable for juicing.

3 Assemble the two parts of the lter (Fig. 4).

4 Place the two-part lter over the juicing screw (Fig. 5).

Tip: Use the black two-part filter for clear juice. If you prefer cloudy juice with

more fibres in it, use the grey two-part filter.

5 Attach the spout to the juicing unit and turn it clockwise until the arrow (

)

points to the ‘locked’ indication. (Fig. 6)

6 Place the berry tray on the feeding tube (Fig. 7).

Placing the juicing unit onto the motor unit

1 Place the assembled juicing unit onto the motor unit, with the pulp outlet

tting into the opening on the motor unit (Fig. 8).

2 Align the projections on the juicing unit with the recesses in the motor unit.

Slide the juicing unit onto the motor unit until it locks into place. (Fig. 9)

3 Press the juicing unit onto the motor unit (1) and then close the locking clamp

(2). (Fig. 10)

Note: If the locking clamp cannot be closed, check if the juicing unit is positioned

properly with the projections on the juicing unit into the recesses of the motor

unit.

4 Slide the pulp container into the motor unit (Fig. 11).

Using the appliance

The appliance only functions if the juicing unit and the pulp outlet are

assembled correctly and the locking clamp is locked properly.

Always unwind the mains cord completely before you switch on the appliance.

1 Wash the fruit and/or vegetables. If necessary, cut them into pieces that t into

the feeding tube.

Note: Remove stones and thick peels of the fruits you would not eat, for example

from oranges, pomegranates etc.

2 Place a jug or a glass under the spout (Fig. 12).

3 Press the on/o button to switch on the appliance (Fig. 13).

4 Put the pieces of fruit or vegetables in the feeding tube and gently press them

down towards the juicing screw with the pusher (Fig. 14).

Never insert your ngers or an object into the feeding tube or juicing unit.

5 When the juice ow has stopped, switch o the appliance and wait until the

juicing screw has stopped rotating.
