10 02/2011
english
8 Technical data
*: only applies to the paper/card cutting unit
Cutting type * Cross cut
Shred size * 1/8“ x 1 1/16“ (3 x 9 mm)
Cutting ca pa ci ty per cycle 1 CD (max. 1.2 mm thick)
or 1 credit card / store card
or 8 sheets of paper (80 g/m²)
9 sheets of paper (70 g/m²)
Cutting speed *
7.9 ft/min (40 mm/s)
Shredded material container volume * 6.6 gal (25 l)
Voltage 120 V / 60 Hz
220 - 240 V, 50 - 60 Hz
Dimensions B x T x H
15.6“ x 10.6“ x 22.5“
(395 x 270 x 580 mm)
Weight 35.3 lbs. (16 kg)
EC Declaration of Conformity
HSM GmbH + Co. KG, Austrasse 1 - 9, D-88699 Frickingen hereby declares that the machine, referred to here as
document shredder HSM shredstar X8pro
corresponds to the health and safety requirements of the following EC directives listed below due to its conception and
design of the version in which it was put into circulation by us:
Low voltage directive 2006 / 95 / EEC
EMC directive 2004 / 108 / EC
Applied standards and technical speci cations:
• EN 13857:2008 • EN 55014-1:2006
• EN 55014-2:1997 + A1:2001 • EN 61000-3-2:2006
• EN 61000-3-3:2008
Frickingen, 26.10.2010
Rolf Gasteier - Technical Director
