SPECIFICATIONS
MODEL DS 70
DS 90
DS 90 X
WHEELS
Front
8x5.5
DS 90 X: 10 x 5.5
Size
Rear
8x7
DS 90 X: 8 x 8.5
Wheel nut torque
Front and
rear
40N•m±4N•m(30lbf•ft±3lbf•ft)
BRAKES
Front
Mechanical, drum
DS 90 X: hydraulic, disc
Rear
Mechanical, drum
DS 90 X: hydraulic, disc
Parking device LH brake lever with parking brake
DIMENSION AND WEIGHT
Dry weight 111 kg (245 lb)
Overall length
152 cm (59.8 in)
Overall width
91 cm (35.8 in)
DS 90 X: 111 cm (43.7 in)
Overall height
93.5 cm (36.8 in)
DS 90 X: 97cm (38.2 in)
Wheelbase
100 cm (39.4 in)
DS 90 X: 102.4 cm (40.3 in)
Ground clearance
11.5 cm (4.5 in)
112
