RIDING THE VEHICLE
Pre-Ride Inspection
WARNING
Perform a pre-ride inspection before each ride to detect any potential prob-
lem thatcouldoccurduring operation. The pre-rideinspection can help you
monitorwearand deteriorationbeforetheybecome a problem. Correctany
problem that you discover to reduce the risk of a breakdown or crash. See
an authorized Can-Am dealer if necessary.
Before using this vehicle, the operator and/or an adult should always perform the
following pre-ride inspection check list.
Pre-Ride Inspection Check List
What to Do Before Starting the Engine (Key OFF)
ITEMS TO BE
INSPECTED
INSPECTION TO PERFORM
✔
Check fuel and engine oil.
Fluids
Check brake system for fluid leaks (DS 90 X).
Leaks
Check for any leaks under vehicle.
Steering
Check if steering operates freely by completely turning it
from side to side.
Activate throttle lever several times to ensure it operates
freely. It must return to idle position when released.
Throttle lever
Ensure the speed limiter screw is properly adjusted
according to rider capability.
Parking brake Apply parking brake and ensure it operates properly.
Tires
Check tire pressure and condition.
Wheels
Check wheels for damage.
Radiator
Check cleanliness of the radiator.
Inspect sprockets for wear or damages.
Drive chain and
sprockets
Check drive chain, slider and drive chain tensioner for
proper adjustment and lubrication (as applicable).
________
SAFETY IN
FORMATION
________
39
