7
EN
• Do not use the batteries if you
nd something wrong with them
such as leakage, color change or
deformity.
• Unplug the charger if the charging
is still incomplete after the
speci ed time it should take.
• Should any batteries liquid get on
skin or clothing, promptly wash it
o with clean water.
• Keep batteries away from  re.
f Caution:
• Do not subject batteries to strong
shocks.
• When using rechargeable batteries
that have not been used for a
while, be sure to recharge them
before use.
• Rechargeable batteries have
limited lifetime. When the
operating time becomes shorter
even if the rechargeable battery is
fully charged under the speci ed
condition, replace it with a new
one.
Getting started
Identification of parts
1 EAR (Earphone) jack
2 MIC (Microphone) jack
3 Built-in microphone
4 Recording indicator light
5 Built-in speaker
6
+
button
7 REC (s) (Record) button
8 9 button
9 FOLDER/INDEX/SCENE
button
0
–
button
! ERASE button
@
`OK/MENU button
# 0 button
$ STOP (4) button
% Display (LCD panel)
^ POWER/HOLD switch
& USB connector
* Battery cover
( Strap hole
Display (LCD panel)
A: When the [
Font Size
] is set to
[
Large
]
B: When the [
Font Size
] is set to
[
Small
]
1 Current file number/ Total number
of recorded files in the folder
2 Folder indicator
3 Recorder status indicator
4 During recording mode:
Elapsed recording time
During playback mode:
Elapsed playback time
5 [?] Microphone Sensitivity
indicator
[!] VCVA indicator
[0] Low Cut Filter indicator
6 File lock indicator
7 Battery indicator
8 Recording mode indicator
9 During recording mode:
Remaining recording time
During playback or stop mode:
File length
0 Playback mode indicator
! File name
*
@ During recording mode:
Remaining memory bar
indicator*
During playback or stop mode:
Playback position bar indicator*
# Recording date and time*
* This item will be displayed when
the [Font Size] is set to [Small]
only.
Inserting batteries (Fig. 1)
1 Lightly press down on the arrow
and slide the battery cover open.
2 Insert size-AAA alkaline battery,
observing the correct = and
- polarities.
3 Close the battery cover completely
by pressing to the direction A,
then sliding to the direction B.
Turning on/off the power (Fig. 2)
Turning on the power:
While the recorder is turned off, slide the
POWER/HOLD
switch in the direction
indicated by the arrow.
Turning off the power:
Slide the
POWER/HOLD
switch in the
direction indicated by the arrow for 1
second or longer.
Power save mode:
If the recorder is stopped/not used
for over 5 minutes after it is turned
on, it goes into standby (power-save)
mode, and the display shuts off. To
exit standby mode and turn on the
display, press any button.
Setting time and date
[
Time & Date
] (Fig. 3)
When you install batteries for the
first time or each time you replace
the batteries, the “Hour” indication
will flash.
1 Press the 9 or 0 button to
select the item to set.
2 Press the + or − button to set.
• Follow the same steps by
pressing the 9 or 0 button
to select the next item, and press
the + or − button to set.
• You can select between 12 and
24 hours display by pressing the
FOLDER/INDEX/SCENE button
while setting the hour and
minute.
• You can select the order of the
“month”, “day” and “year” by
pressing the FOLDER/INDEX/
SCENE button while setting
them.
3 Press the `
OK /MENU
button to
complete the setting.
• The clock will start from the
set date and time. Press the
`OK/MENU button according to
the time signal.
Notes on the Folders
The recorder provides five folders,
[F], [G], [H], [I] and [W]. To
change the folder selection, press
the FOLDER/INDEX/SCENE button
while the recorder is stopped. Each
folder can store up to 200 files.
