CS1922M / CS1924M RS-232 Commands

RS-232 Commands

After you login via HyperTerminal (see page 5) use the instructions below to

send RS-232 commands to control the switch from the computer.

When RS-232 control is enabled via the Open + [Enter] command, the

CS1922M / CS1924M’s front panel pushbuttons, mouse switching and hotkeys

will be disabled, until the serial connection is closed.

For detailed information about the controls listed in this guide, please refer to

the CS1922M / CS1924M user manual.

Verification

After entering a command, a verification message appears, as shown below, at

the end of the command line, as follows:

With all commands in the sections that follow:

 Each command string can be separated with a space.

 The [Enter] command can be replaced with the ASCII code: 0x0D0A

Response Message Description

Command OK Command or parameter is correct.

Command incorrect Command or parameter is incorrect.
