4. OSD Operation

 The diagram depicts the administrator's main screen. The user main screen

does not show the F4 and F6 functions, since these are reserved for the

administrator and can't be accessed by users.

 The OSD always starts in list view, with the highlight bar at the same

position it was in the last time it was closed.

 Only the ports that have been set accessible by the administrator for the

current logged in user are visible (see SET ACCESSIBLE PORTS,

page 39).

 Enable Mouse Emulation to operate the OSD using mouse. When the

Mouse Emulation is disabled, you can only operate the OSD using

keyboard.

a) To enable the Mouse Emulation via OSD, see Mouse Emulation,

page 41.

b) To enable the Mouse Emulation via hotkeys, see Mouse Emulation

Control, page 55.

 If the port list is collapsed, click on a switch number, or move the highlight

bar to it then press the Enter key to expand the list. Similarly, to collapse a

switch’s port list, click on the switch number, or move the highlight bar to

it then press the right Enter key to collapse the list.

OSD Main Screen Headings

OSD Navigation

 To dismiss the menu, and deactivate OSD, click

at the upper right

corner of the OSD window; or press [Esc].

PN This column lists the port ID numbers for all the KVM ports on the

installation. The simplest method to access a particular computer is

move the highlight bar to it, then press Enter.

QV If a port has selected for quick view scanning (see SET QUICK VIEW

PORTS, page 40), a check mark

(

√

)

displays in this column.

PW The computers that are powered on and are online have a sun symbol

in this column .

NAME If a port has been given a name (see EDIT PORT NAMES, page 40), its

name appears in this column.
