ATEN Secure KVM User Manual
8
No.
Component
Description
1
Port Selection
Pushbuttons
Pressing a Port Selection Pushbutton brings together the keyboard,
mouse, video, audio, and CAC reader focus to the computer attached
to its corresponding port.
2
Port and CAC LEDs
The Port / CAC LEDs are located on front panel to indicate Port/CAC
reader selection or connection status.
Port LEDs (Lower row; Orange LEDs)
� Online – Lights dim orange to indicate that the computer attached to
its corresponding port is connected and powered on.
� Selected – Lights bright orange to indicate that the computer
attached to its corresponding port has the KVM focus.
� Warning - Flashes to indicate that a non-qualified USB HID device is
connected to console USB keyboard port or mouse port when the
corresponding port has the focus.
CAC LEDs (Upper row, Green LEDs, CAC models only)
� Online – Lights dim green to indicate that the computer attached to
its corresponding port has a USB CAC reader cable connection and
the CAC function is enabled.
� Selected – Lights bright green to indicate that the CAC function is
enabled and the computer attached to its corresponding port has the
CAC focus.
�None – No lights indicate that the cable is not connected or CAC has
been disabled.
� Warning - Flashes to indicate that a non-qualified USB smart card /
CAC reader is connected when the corresponding port has the focus.
Note:
1. CAC function of each port can be enabled or disabled by pressing
the port selection pushbutton for more than 3 seconds (this is a
toggle feature). Please refer to the Operation section of this user
manual for more information.
2. All front panel LEDs (except the Power LED) will flash
continuously when a chassis intrusion or self-test failure (except
for Pushbutton jam) is detected. See Chassis Intrusion Detection
section for further details.
3. Port and CAC LEDs also indicate the status of the Secure KVM
self-test status. See Operation section for further details
3
Reset Button
Press this button to reset the ATEN Secure KVM Switch.
Note:
When you perform a reset by pressing the reset button for more than 5
seconds, the keyboard/mouse buffer will be purged and the switch will
reboot and perform a self-test. After a successful self-test, port focus
will be switched to port 1, and the CAC function of each port will be set
