ATEN Secure KVM User Manual
viii
About This Manual
This user manual is intended for system administrators and end users.
This user manual is provided to help you get the most from your ATEN Secure KVM Switch system. It
covers all aspects of installation, configuration and operation. An overview of the information found in
the manual is provided below.
This user manual covers the following ATEN Secure KVM Switches:
Configuration (with CAC function)
2-Port
4-Port
8-Port
PC Video
Connection
Console Video
Connection
No. of Displays
DisplayPort
DisplayPort
Single
CS1182DP4C
CS1184DP4C
CS1188DP4C
Dual
CS1142DP4C
CS1144DP4C
CS1148DP4C
HDMI
HDMI
Single
CS1182H4C
CS1184H4C
NA
Dual
CS1142H4C
CS1144H4C
NA
DVI
DVI
Single
CS1182D4C
CS1184D4C
CS1188D4C
Dual
CS1142D4C
CS1144D4C
CS1148D4C
Configuration (without CAC function)
2-Port
4-Port
8-Port
PC Video
Connection
Console Video
Connection
No. of Displays
DisplayPort
DisplayPort
Single
CS1182DP4
CS1184DP4
CS1188DP4
Dual
CS1142DP4
CS1144DP4
CS1148DP4
HDMI
HDMI
Single
CS1182H4
CS1184H4
NA
Dual
CS1142H4
CS1144H4
NA
DVI
DVI
Single
CS1182D4
CS1184D4
CS1188D4
Dual
CS1142D4
CS1144D4
CS1148D4
ATTENTION
If the tamper-evident seal is missing or peeled, avoid using the product and contact your
ATEN dealer.
If all front panel LEDs on the Secure KVM Switch (except Power) flash continuously, all
Remote Port Selector (RPS) LEDs flash, or either enclosure appears breached, avoid using
the product and contact your ATEN dealer.
The Secure KVM Switch and the Remote Port Selector (RPS) are equipped with active
always-on chassis intrusion detection security. Any attempt to open the enclosure will
permanently disable the switch/ RPS, and void the warranty.
Tamper-evident seal
