![Aten CS1184D4 [20/46] Aten secure kvm user manual](/views2/1977539/page20/bg14.png)
ATEN Secure KVM User Manual
9
to factory default setting (enabled).
If the Secure KVM fails to generate video on the monitor after a reset,
please power off the installation, check the cables, and follow the
instructions found in this manual to power on the installation.
4
Audio Ports
The cables from your speakers plug in here.
Note: Only standard analogue speaker connections are allowed. The
use of an analogue microphone or line-in audio device is strictly
prohibited.
5
USB Smart Card / CAC
Reader Port
(CAC models only)
Only qualified USB authentication devices (e.g., standard smart card
and CAC reader) can be plugged into this port.
Note: USB authentication device filter is configurable by authorized
administrators for trusted devices (e.g. USB token, USB Biometric
reader). Please refer to the Administrator Guide for details.
6
Num Lock LED
Lights green to indicate the Num Lock function has been turned on.
Note: The Num Lock LED on the keyboard will be disabled due to
security requirements.
7
Caps Lock LED
Lights green to indicate the Caps Lock function has been turned on.
Note: The Caps Lock LED on the keyboard will be disabled due to
security requirements.
8
Scroll Lock LED
Lights green to indicate the Scroll Lock function has been turned on.
Note: The Scroll Lock LED on the keyboard will be disabled due to
security requirements.
9
Power LED
Lights green to indicate that the ATEN Secure KVM Switch is powered
on.
10
USB Console Ports
The USB keyboard and mouse plug into these ports. The USB console
keyboard port (lower port) and mouse port (upper port) support the
following – standard USB keyboards/mice, standard USB
keyboards/mice via a USB hub, and the HID functions of a composite
device.
Note:
1. The console USB keyboard and mouse ports are interchangeable,
meaning you can connect a keyboard to the mouse port and vice
versa. However, for optimal operation it is recommended to
connect the USB keyboard to the console's USB keyboard port
and the USB mouse to the console's USB mouse port.
For security purposes, do not attempt to connect a wireless
keyboard or mouse to the switch.
2. Non-standard keyboards/mice with integrated USB hubs and/or
other USB-integrated devices may not be fully supported due to
the strict security standards and policy of the ATEN Secure KVM
Switch. If supported, only basic (HID) keyboard/mouse operations
will function.
3. Multimedia keys on the keyboard will not function due to the
