ATEN Secure KVM User Manual

6. Plug the USB Smart Card / CAC reader to the console CAC port on the front panel. (Optional)

7. Plug the cable on the RPS into the console RPS port. (Optional)

8. Plug the female end of the power cord into the ATEN Secure KVM Switch power socket; plug the

male end into an AC power source.

9. Turn on the ATEN Secure KVM Switch and check that the LEDs light up. The ATEN Secure

KVM Switch will start a self-test.

Note:

1. Only appropriate qualified USB authentication devices (e.g., Smart Card and CAC readers by

default) can be plugged into this port. During KVM operation, non-qualified or non-authorized

USB devices will be filtered and rejected (the CAC LED that has port focus will flash). Please

refer to the LED display for visual indications.

2. The CDF (Configurable Device Filtration) function can only be operated by authorized

administrators. Please refer to the Administrator Guide and Port Authentication Utility Guide for

details.

3. An active session on the selected computer is immediately terminated upon removal of the CAC

card.

Note:

1. Verify that the second video plug is in the same KVM port section as the first video plug (all in

Port 1, all in Port 2, etc.). Each socket is marked with an appropriate icon.

2. Repeat steps 4, 5 for each computer you are installing.

3. With a dual-display installation, for easier cabling at your site, you can also connect all the

primary video connectors to video sockets B, and secondary video connectors to video sockets

A. Make sure the console’s primary and secondary monitors are connected the same way.

Note:

The ATEN Secure KVM Switch performs a security self-test at power-on and at each power cycle.

Front panel LEDs will indicate the self-test status and test result. Please refer to the Operation section

and LED Display section for visual identification details.

Note:

1. Be sure to connect the RPS before the ATEN Secure KVM Switch is powered-on.

2. Any connection of RPS after the ATEN Secure KVM Switch is powered-on will not be detected

by the switch.
