ATEN Secure KVM User Manual

Requirements

Console

� DVI (for DVI-interfaced Secure KVM), HDMI (for HDMI interfaced Secure KVM), or DisplayPort

(for DisplayPort-interfaced Secure KVM) monitor capable of the highest resolution that you will be

using on any computer in the installation

� USB mouse

� USB keyboard

� Speaker (Optional)

� USB Smart card or CAC (Common Access Card) reader (Optional)*

� Remote Port Selector (Optional)**

Computers

� A DVI/HDMI/DisplayPort video output connector

� A USB Type A port for keyboard and mouse

� A USB Type A port for Smart Card or CAC reader (Optional)*

� A 3.5 mm jack Audio port for speaker (Optional)

Cables

The KVM cable sets which are specifically designed to work with this switch are not supplied in the

package and require a separate purchase.

For security, do not connect any cable that has a microphone audio input or line in audio input.

Note:

* Only applicable on the models with CAC function

** Remote Port Selector is not supplied in the package and requires a separate purchase
