ATEN Secure KVM User Manual
30
CAC activated
2 (Green)
4 (Green)
8 (Green)
NA
Power
1 (Green)
1 (Green)
Key Lock LED
3 (Green; Num Lock, Caps Lock, Scroll Lock)
3 (Green; Num Lock, Caps Lock, Scroll Lock)
Console Video
2 (Green, on back panel)
2 (Green, on back panel)
Emulation
Keyboard/Mouse
USB
USB
Video
Max. 3840 x 2160 @ 30 Hz (UHD)
Max. 3840 x 2160 @ 30 Hz (UHD)
I/P Rating
100–240V~ ;
50-60 Hz; 1A
100–240V~ ; 50-60 Hz; 1.5A
100–240V~ ;
50-60 Hz; 1A
(TBD)
100–240V~ ; 50-60 Hz; 1.5A
Environment
Operating Temp.
0–50°C
0–50°C
Storage Temp.
-20–60°C
-20–60°C
Humidity
0–80% RH, Non-condensing
0–80% RH, Non-condensing
Physical Properties
Housing
Metal
Metal
Weight
2.13kg (TBD)
2.18kg (TBD)
3.22kg (TBD)
2.13kg (TBD)
2.18kg (TBD)
3.22kg (TBD)
Dimensions
(L x W x H)
335 x 164 x
66 mm
335 x 164 x
66 mm
432 x 205 x
66 mm
335 x 164 x
66 mm
335 x 164 x
66 mm
432 x 205 x
66 mm
ATEN Single Display HDMI Secure KVM (CAC and Non-CAC models)
Function
CS1182H4C
CS1184H4C
CS1182H4
CS1184H4
Computer
Connections
Direct
2
4
2
4
Max.
2
4
2
4
Console Connections
1 Direct
1 Direct
Port Selection
Pushbutton, Remote Port Selector
Pushbutton, Remote Port Selector
Connectors
Console
Ports
Keyboard
1 x USB Type A Female
1 x USB Type A Female
Video
1 x HDMI Female (Black)
1 x HDMI Female (Black)
Mouse
1 x USB Type A Female
1 x USB Type A Female
Speaker
1 x Mini Stereo Jack Female (Green)
1 x Mini Stereo Jack Female (Green)
Microphone
N/A
NA
CAC
1 x USB Type A Female
NA
KVM Ports
Keyboard/
Mouse
2 x USB-B Female
4 x USB-B Female
2 x USB-B Female
4 x USB-B Female
Video
2 x HDMI Female
4 x HDMI Female
2 x HDMI Female
4 x HDMI Female
CAC
2 x USB-B Female
4 x USB-B Female
NA
Speaker
2 x Mini Stereo Jack
Female
4 x Mini Stereo Jack
Female
2 x Mini Stereo Jack
Female
4 x Mini Stereo Jack
Female
Microphone
N/A
NA
