Aten VM5404HA [102/124] Scaling command
![Aten VM5404HA [102/124] Scaling command](/views2/1977702/page102/bg66.png)
VM5404HA / VM5808HA User Manual
90
Scaling Command
The Scaling command allows you to set a resolution for scaling the display
connected to an output port.
The formula for the Scaling command is as follows:
Command + Output + Number 1 + Horizontal Resolution + Number 2
+ Vertical Resolution + Number 3 + Frequency + Number 4 + Control
+ [Enter]
1. For example, to turn scaling off for output port 02, type:
scaling o02 off [Enter]
2. To set the scaling for output port 04 to 1920x1080@60Hz, type:
scaling o04 1080p [Enter]
3. To set the scaling for all output ports to the connected display’s native
resolution, type:
scaling o* native [Enter]
The following tables show the possible values for the Scaling command:
Command Description
scaling Scaling command
Output Description
o Output command
Port Number Description
yy 01-08 port
* All output ports
Horizontal
Resolution
Description
hor Horizontal resolution command for
scaling
Resolution Number Description
hhhh Horizontal resolution
Vertical Resolution Description
ver Vertical resolution command for
scaling
