Skil 1840 LA [10/140] Application advice
![Skil 1840 LA [10/140] Application advice](/views2/1097777/page10/bga.png)
Содержание
- F0151840 1
- Lzi 1 1 nt л 1 j 131 1
- Router 1840 1
- Introduction 7
- Personal safety 7
- Router 1840 7
- Safety 7
- Technical data 7
- Tool elements 7
- Application advice 10
- Caracteristiques techniques 10
- Declaration of conformity c 10
- Défonceuse 1840 10
- Elements de l outil 10
- Environment 10
- Introduction 10
- Maintenance service 10
- Securite 11
- Instructions de securite pour defonceuses 12
- Utilisation 13
- Conseils d utilisation 14
- Déclaration de conformite c 14
- Entretien service apres vente 14
- Environnement 14
- Einleitung 15
- Oberfräse 1840 15
- Sicherheit 15
- Technische daten 15
- Werkzeugkomponenten 15
- Bedienung 17
- Anwendungshinweise 18
- Umwelt 18
- Wartung service 18
- Bovenfrees 1840 19
- Introductie 19
- Konformitätserklärung c 19
- Machine elementen 19
- Technische gegevens 19
- Veiligheid 19
- Gebruik 21
- Onderhoud service 22
- Toepassingsadvies 22
- Conform iteitsverklaring c 23
- Handöverfräs 1840 23
- Introduktion 23
- Milieu 23
- Sakerhet 23
- Tekniska data 23
- Verktygselement 23
- Användning 25
- Användningstips 26
- Försäkran om överensstämmelsec 26
- Miljö 26
- Underhäll service 26
- Inledning 27
- Overfræser 1840 27
- Sikkerhed 27
- Tekniske data 27
- Værkt0jets dele 27
- Betjening 29
- Gode rad 30
- Overensstemmelseserklzering c 30
- Vedligeholdelse service 30
- Fres 1840 31
- Introduksjon 31
- Sikkerhet 31
- Tekniske data 31
- Verkt0yelementer 31
- Brukertips 34
- Esittely 34
- Laitteen osat 34
- Samsvarserklzering c 34
- Tekniset tiedot 34
- Vedlikehold service 34
- Yläjyrsin 1840 34
- Turvallisuus 35
- Kayttò 36
- Vinkkejá 37
- Datos técnicos 38
- Elementos de la herramienta 38
- Fresadora 1840 38
- Hoito huolto 38
- Introducción 38
- Seguridad 38
- Vaatimusten mukaisuusvakuutusc 38
- Ympàristònsuojelu 38
- Ambiente 42
- Consejos de aplicación 42
- Dados técnicos 42
- Declaración de conformidad c 42
- Introdução 42
- Mantenimiento servicio 42
- Tupia 1840 42
- Elementos da ferramenta 43
- Segurança 43
- Manuseamento 45
- Ambiente 46
- Conselhos de aplicação 46
- Declaração de conformidade c 46
- Manutenção serviço 46
- Dati tecnici 47
- Elementi utensile 47
- Fresatrice 1840 47
- Introduzione 47
- Sicurezza 47
- Consiglio pratico 50
- Dichiarazione dei conformità c 50
- Manutenzione assistenza 50
- Tutela dell ambiente 50
- Bevezetés 51
- Biztonsàg 51
- Felsómaró 1840 51
- Müszaki adatok 51
- Szerszàmgép elemei 51
- Kezelés 53
- Használat 54
- Karbantartás szerviz 54
- Bezpecnost 55
- Hornifrézka 1840 55
- Kòrnyezet 55
- Megfelelóségi nyilatkozatc 55
- Soucásti nástroje 55
- Technická data 55
- Obsluha 57
- Nàvod k pouzitì 58
- Prohlasenì 0 shodèc 58
- Zivotnì prostredì 58
- Ùdrzba servis 58
- Alet bîleçenlerî 59
- Freze 1840 59
- Gîrîs 59
- Gùvenlìk 59
- Teknìk verîler 59
- Kullanim 61
- Bakim servis 62
- Uygulama 62
- Uygunluk beyanic 62
- Çevre 62
- Bezpieczeñstwo 63
- Dane techniczne 63
- Elementy narz dzia 63
- Frezarka 1840 63
- Podczas uèywania 65
- Uzytkowanie 65
- Konserwacja serwis 66
- Srodowisko 66
- Wskazowki uzytkowania 66
- Deklaracja zgodnosci c 67
- Безопасность 67
- Введение 67
- Детали инструмента 67
- Технические данные 67
- Фрезер 1840 67
- Использование 70
- Постучите по гайке патрона в ключом с 70
- Декларация о соответствии стандартам с 71
- Охрана окружающей среды 71
- Советы по использованию 71
- Техобслуживание сервис 71
- Безпека 72
- Вступ 72
- Елементи 1нструмента 72
- Техн1чн1 дан1 72
- Фрезарка 1840 72
- Використання 74
- Догляд обслуговування 75
- По ради по використаню 75
- Texnika хар akthp ietika 76
- Ахфаае1а 76
- Декларац1я про в1дпов1дн1сть стандартам с 76
- Ееагпгн 76
- Мерн toy ергааеюу 76
- Охорона навколишньот середи 76
- Роитер 1840 76
- I гю 80
- Nowvsidau 80
- Oipripido s disyoads ря1р1яэур oí sipisu лрц 80
- Pio гапзупод ол isusdu boo oisyoads oí 80
- Zhjoi mdvoh zhuhvo 80
- Zhzu0doiall mâz hzuvhv 80
- Zisdaz hzhdhinaz 80
- Гюг wii ьог1о1лолоя зз яз ег u боог зз еэл 80
- Зюз рарзюя oiouo лр1 оюлрфшэ лр11зордф oisyoads ряииоя oi noiodu oidinxoi рю1азт1 80
- Лспятяю одря лою оюопзяопо юя 80
- Мз гиэоог xa soi wos лпидрдо лон bu ari 80
- Олтфг1по moss n3 00019 n3 9v 09 ns bi3opiono 80
- Ьоюдпз рлрдо noi oimdu эююпаодоипло 80
- Ьриоя 80
- Datetehnice 81
- Elementele sculei 81
- Introducere 81
- Masini de frezat 1840 81
- Siguranta 81
- Utilizarea 83
- Întimpul functionàrii 83
- Mediul 84
- Sfaturi pentru utilizare 84
- Întretinere service 84
- Declaratie de conformitate c 85
- Безопасност 85
- Елементи на инструмента 85
- Оберфреза 1840 85
- Технически данни 85
- Увод 85
- Употреба 88
- Декларация за съотвегствие с 89
- Опазване на околната среда 89
- Поддръжка сервиз 89
- Указания за работа 89
- Bezpecnost 90
- Casti nästroja 90
- Horna fréza 1840 90
- Technické üdaje 90
- Pouzitie 92
- Radu na pouzitie 93
- Zivotné prostredie 93
- Ùdrzba servis 93
- Dijelovi alata 94
- Glodalica 1840 94
- Sigurnost 94
- Tehnicki podaci 94
- Vyhlásenie o zhode c 94
- Posluzivanje 96
- Deklaracij a 0 sukladnosti c 97
- Odrzavanje servisiranje 97
- Savjetiza primjenu 97
- Zastita okolisa 97
- Elementi alata 98
- Glodalica 1840 98
- Sigurnost 98
- Tehnicki podaci 98
- Uputstvo 98
- Uputstvo za koriscenje 100
- Deklaracija 0 uskladenosti c 101
- Odrzavanje servis 101
- Saveti za primenu 101
- Zastita okoline 101
- Deli orodja 102
- Struznica 1840 102
- Tehnicni podatki 102
- Varnost 102
- Uporaba 104
- Izjava 0 skladnostic 105
- Okolje 105
- Uporabni nasveti 105
- Vzdrzevanje servisiranje 105
- Ohutus 106
- Seadme osad 106
- Sissejuhatus 106
- Tehnilised andmed 106
- Ülafrees 1840 106
- Kasutamine 108
- Hooldus teenindus 109
- Ievads 109
- Instrumenta elementi 109
- Keskkond 109
- Tehniskie parametri 109
- Tòòjuhised 109
- Vastavusdeklaratsioon c 109
- Virsfrëze 1840 109
- Drosiba 110
- Apkalposana apkope 113
- Apkàrtéjàs vides aizsardzìba 113
- Atbilstìbas deklaràcijac 113
- Praktiski padomi 113
- Fvadas 114
- Prietaiso elenientai 114
- Techniniai duomenys 114
- Vertikaliojo frezavimo masina 1840 114
- Naudojimas 116
- Aplinkosauga 117
- Atitikties deklaracijac 117
- Naudojimo patarimai 117
- Prieziùra servisas 117
- Безбедност 118
- Елементи на алатот 118
- Насочувач 1840 118
- Технички податоци ф 118
- Упатство 118
- Употреба 120
- Одржуванэе сервисиранэе 121
- Совети за прим ена 121
- Elementet e pajisjes 122
- Freze shkallèzuese 1840 122
- Siguria 122
- Té dhénat teknike 122
- Декларации за усогласеност с 122
- Заштита на жи both ат а средина 122
- Pérdorimi 124
- Kèshillè pèr pérdorimin 125
- Deklarata e konform itetit 126
- Mirémbajtja shèrbimi 126
- Mjedisi 126
- Ai i ii 128
- Ufchjf 128
- Î nil 130
- Hmihmни пши шнншпншшшн 131
- I ì f b ï f 131
- Un l нни1 131
- Uu hhh hhèuhhh 131
- Llk l uluji ji uhi 132
- Marijn van der hoofden operations engineering 132
- Olaf dijkgraaf approval manager 132
- Skil europe bv 4825 bd breda nl 132
- Ui llgoiuilpll g ii 132
- Ôb l ob s o 134
- Üji obuji 134
- Дата производства 140
Похожие устройства
- Sony MVC-FD73 Инструкция по эксплуатации
- Electrolux ESL6550RO Инструкция по эксплуатации
- Skil 0560 AC Инструкция по эксплуатации
- Sony MVC-FD71 Инструкция по эксплуатации
- Whirlpool WTV 4597 NFC IX Инструкция по эксплуатации
- Skil LL0516 AD Инструкция по эксплуатации
- Whirlpool WTV 4595 NFC TS Инструкция по эксплуатации
- Sony MVC-FD7 Инструкция по эксплуатации
- Skil LL0516 AB Инструкция по эксплуатации
- Sony MVC-FD51 Инструкция по эксплуатации
- Liebherr CN 5113-21 Инструкция по эксплуатации
- Sony MVC-FD200 Инструкция по эксплуатации
- Skil 0510 AB Инструкция по эксплуатации
- Sony MVC-FD100 Инструкция по эксплуатации
- Skil 0502 AA Инструкция по эксплуатации
- Samsung RS552NRUA1J Инструкция по эксплуатации
- Sony MVC-CD500 Инструкция по эксплуатации
- Samsung RS552NRUASL RS552NRUASL Инструкция по эксплуатации
- Skil DT0551 AB Инструкция по эксплуатации
- Sony MVC-CD400 Инструкция по эксплуатации
APPLICATION ADVICE NOISE VIBRATION Measured in accordance with EN 60745 the sound pressure level of this tool is 84 dB A and the sound power level 95 dB A standard deviation 3 dB and the vibration 4 4 m s2 hand arm method uncertainty K 1 5 m s2 The vibration emission level has been measured in accordance with a standardised test given in EN 60745 it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned using the tool for different applications or with different or poorly maintained accessories may significantly increase the exposure level the times when the tool is switched off or when it is running but not actually doing the job may significantly reduce the exposure level I protect yourself against the effects of vibration by maintaining the tool and Its accessories keeping your hands warm and organizing your work patterns For cuts parallel with the side of your workpiece use parallel guide For making parallel cuts in a workpiece far from the edge fasten a straight piece of wood on the workpiece by means of 2 clamps guide tool with base plate along edge of wood which now functions as a parallel guide When using bits with a pilot or ball bearing the pilot or ball bearing should slide along the edge of the workpiece which should be perfectly smooth For larger routing depths it is recommended to carry out several repetitive cuts with lower removal rates MAINTENANCE SERVICE This tool is not intended for professional use Always keep tool and cord clean especially ventilation slotsS Lubricate sliding bars T occasionally If the tool should fail despite the care taken in manufacturing and testing procedures repair should be carried out by an after sales service centre for SKIL power tools send the tool undismantled together with proof of purchase to your dealer or the nearest SKIL service station addresses as well as the service diagram of the tool are listed on www skil com Défonceuse INTRODUCTION Loutil est conçu pour le fraisage des rainures bords profils et rainures droites dans le bois les matières plastiques et matériaux de construction légers ainsi que pour le fraisage par copiage Cet outil n est conçu pour un usage professionnel Lédairage de cet outil électroportatif est destiné à éclairer l espace de travail de l outil il n est pas conçu pour servir de source d éclairage ambiant dans une pièce Lisez et conservez ce manuel d instruction ENVIRONMENT Do not dispose of electric tools accessories and packaging together with household waste material only for EU countries in observance of European Directive 2012 19 EC on waste of electric and electronic equipment and its implementation in accordance with national law electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility symbol will remind you of this when the need for disposing occurs CARACTERISTIQUES TECHNIQUES ELEMENTS DE L OUTIL A Blocage de l arbre B Chapeau C Clé D Jauge de profondeur E Bouton de réglage précis F Tourelle de butées de profondeur G Bouton de réglage jauge de profondeur H Levier de verrouillage J Molette pour régler I a vi tesse K Axe pour aspirateur L Interrupteur marche arrét M Bouton de blocage de l interrupteur N Bouton de réglage poignée O Voyants DEL P Plaque adaptatrice Q Guide parallèle R Plaque de base S Fentes de ventilation T Axes de guidage V Tiges du guide parallèle DECLARATION OF CONFORMITY C We declare under our sole responsibility that the product described under Technical data is in conformity with the following standards or standardization documents EN 60745 EN 61000 EN 55014 in accordance with the provisions of the directives 2004 108 EC 2006 42 EC 2011 65 EU 2009 125 EC EU regulation 1194 2012 Technical file at SKIL Europe BV PT SEU ENG1 4825 BD Breda NL Marijn van der Hoofden Operations Engineering 1840 Olaf Dijkgraaf Approval Manager SKIL Europe BV 4825 BD Breda NL 09 12 2013 10
