Additional information
When the mode dial is set to (when [MOVING IMAGE] is set to [CLIP MOTION] in the SET UP settings)
* MVC-CD400 only
Item Setting Description
(EV)
(MVC-CD250 only)
+2.0EV / +1.7EV / +1.3EV / +1.0EV /
+0.7EV / +0.3EV / x0EV /
–0.3EV /
–0.7EV / –1.0EV / –1.3EV / –1.7EV /
–2.0EV
Adjusts the exposure value (page 70).
9 (FOCUS)
(MVC-CD250 only)
∞ / 7.0 m / 3.0 m / 1.0 m / 0.5 m /
CENTER AF / xMULTI AF
Selects the auto focus method or sets the focus preset.
WB (WHITE BAL)
* / / / / / xAUTO Sets the white balance (page 76).
(
SPOT METER
)
(MVC-CD250 only)
ON / xOFF Adjusts the exposure to the subject you are shooting (page 72).
(IMAGE SIZE) xNORMAL / MOBILE Selects the Clip Motion image size (page 77).
±
(FLASH LEVEL) HIGH
xNORMAL
LOW
– Makes the flash level higher than normal.
– Normal setting.
– Makes the flash level lower than normal.
PFX (P.EFFECT) SOLARIZE / B&W / SEPIA /
NEG.ART / xOFF
Sets the image special effects (page 83).
(SHARPNESS) +2 / +1 / x0 / –1 / –2 Adjusts the sharpness of the image. The indicator appears (except when the
setting is 0).
