21
Chapter 3
Basic Operation and
First Time Setup
Operation Methods
ATEN eco PDU models provide three methods to access and manage your
installation: Browser, eco DC (eco PDU management web GUI), and SNMP.
Note: The following sections of this chapter contain information concerning
Browser operation. For eco DC operation, please reference the separate
eco DC user manual. The eco DC and user manual can be downloaded
from the ATEN website.
Browser
ATEN eco PDUs can be accessed and controlled via any supported Internet
browser from any platform. See First Time Setup, page 23, and the following
sections in this chapter, for full details.
eco DC
All eco PDUs support eco DC (Energy & DCIM Management Web GUI). eco
DC provides you with an easy method for managing multiple devices, offering
an intuitive and user-friendly GUI that allows you to configure eco PDUs and
monitor power status of all equipment connected. To install the software,
please visit the product web page, and then download the installer from the
Support and Downloads tab.
SNMP
eco PDUs support any 3rd party V1, V2 & V3 SNMP Manager Software. To
install the software, please visit the product web page, and then download the
installer from the Support and Downloads tab.
