![Aten PE6324 [15/76] Management](/views2/1978030/page15/bgf.png)
Chapter 1. Introduction
5
Management
Power status measurement at the PDU/Bank level
LED indicators for current and IP address at the PDU device and/or Bank
levels.
Real-time aggregate current, voltage, and power and power dissipation
displayed in a browser-based UI for monitoring at the PDU level (PE6216)
and at the bank level (PE6324)
Environment monitoring — supports external temperature / humidity /
differential pressure sensors for environmental condition monitoring
Current and voltage threshold setting
Naming support for outlets
User outlet access assignment on an outlet-by-outlet basis.
Event logging and Syslog support
Upgradeable firmware
Multi-language support: English, Traditional Chinese, Simplified Chinese,
Japanese, German, Italian, Spanish, French, Russian, Korean, Portuguese.
Security
Two-level password security
Strong security features include strong password protection and advanced
encryption technologies — TLS 1.0
Remote authentication support: RADIUS
eco DC Energy Management Web GUI
Automatic discovery of all PE devices within the same LAN
Remote real-time power measurement and monitoring
Real-time environment sensor monitoring
Plotting/monitoring of all PE devices
Exceed threshold alert through SMTP and system log
Power analysis report
Note: eco Senors is designed to work with ATEN PDUs, and is bundled with
all PE series packages.
