Aten PE5224TA [87/88] Administrator login failure

Appendix

Administrator Login Failure

If you are unable to perform an Administrator login (because the Username and

Password information has become corrupted, or you have forgotten it, for

example), you can clear the login information with the following procedure:

1. Power off the eco PDU and remove its housing.

2. Short the jumper labeled J2 (PIN1 and PIN2).

3. Power on the eco PDU.

4. After the beep indicates successfully powered on, power off the switch.

5. Remove the jumper cap from J2.

6. Close the housing and start the eco PDU.

After you start, you can use the default Username and Password to log in.
