Aten UC8000 [22/53] Tuning your audio devices

MicLIVE™ 6-CH User Manual

4. Tuning Your Audio Devices

Tuning Each Audio Track Independently

To test and tune a main / sub audio, do the following.

1. First, mute all incoming audio except for the one you are tuning using 1 of

the 2 following methods.

 on MicLIVE™ 6-CH Mixer: to mute an audio, select that audio by

pressing , , or (press once or twice for input 3 or 4).

Then press .

 via OnAir™ Audio: to mute an audio, click Mute below that audio.

2. Second, make sure your headphones are properly connected and have an

adequate output volume by adjusting the mixer’s .

3. Select the main / sub audio you want to test and tune by pressing ,

, or (press once or twice for input 3 or 4) on the mixer.

4. Then select the input modes you want to set it as:

 Ins. (Instrumental) : applies EQ settings that are ideal for

musical instruments. Press to activate or long press to enable / disable

the Ins. (Instrumental) function.

 +48 V : applies +48 V to microphones that require so. Press to

activate or long press to enable / disable the +48 V function.
