Chapter 1. Introduction

7 MIC Switches to the MIC audio source.

The button will light up when switched to this source.

8 L / R Switches to the RCA Line In audio source.

The button will light up when switched to this source.

9 mute Mutes / unmutes the audio the system is currently tuned

into.

When muting source 1 or 2, AFV will also be turned off.

Video Section (controls the video settings of the system)

10 scenes selector Selects the current stream (PGM) scene and the preview

(PRV) scene.

Greenly lit button indicates PRV Preview.

Redly lit button indicates PGM Preview.

Transition Control Section (switches the current stream (PGM) scene to the preview

(PRV) stream and vice versa)

11 auto (transition) Pressing the Auto button will begin the transition after a

specified time (0.3-3.0 seconds).

Go to the Setting Deck and refer to page 52 on how to

modify this specified time.

Press and hold for 3 seconds to enter Quick Mode. Refer

to Quick Mode on page 62 for more information.

12 cut (transition) The transition happens immediately when you press the

Cut button.

Press and hold for 3 seconds to enter Quick Mode. Refer

to Quick Mode on page 62 for more information.

13 T-Bar (transition) Slide the T-Bar to start the transition. The scene

transition speed depends on how fast you slide the bar.

Sliding the T-bar all the way to one end will complete the

transition.

You can create different effects by sliding it slowly, quickly

or even hold it half way.

14 iPad stand Allows the iPad to sit in.

15 SRC / PGM view

selector

Pressing the button will switch video source between

HDMI source 1, HDMI source 2 and PGM.

16 pause stream Press this button to pause streaming.

17 GoLive Press this button to start streaming and/or recording.

Press again to stop.

No. Component Description
