UCE32100 User Manual
vi
About this Manual
This user manual is provided to help you get the most from the UCE32100 unit.
It covers all aspects of installation, configuration, and operation. An overview of
the information found in the manual is provided below.
Chapter 1, Introduction introduces you to the UCE32100 4-Port USB 2.0 CAT
5 Extender (100m). Its purpose, features, and panel components are presented
and described.
Chapter 2, Hardware Setup describes the steps that are necessary to quickly
and safely set up your installation.
Chapter 3, Operation explains the LED behaviors of the UCE32100 units.
An Appendix provides a list of safety instructions and precautions, contact
information for ATEN technical support, product specifications, and other
technical information.
Note:
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or any connected
devices.
ATEN regularly updates its product documentation for new features and
fixes. For an up-to-date UCE32100 documentation, visit http://
www.aten.com/global/en/
