SNR SR2225RS [7/195] Symbol convention

Symbol convention:

Note: It is used to transmit equipment or environmental safety warning messages. If not avoided, it may

cause equipment replacement, data loss, equipment performance degradation or other unpredictable

results.

Warning: Used to warn of potentially dangerous situations, which, if unavoidable, may cause death or serious

personal injury.

Red arrow: means pointing to a certain position.

Blue arrow: represents the action of pulling out or inserting downward or tilting.

Hollow arrow: represents the next action or result.

Dark blue rotating arrow 1: represents the action of turning the screw clockwise or pulling

out.

Dark blue rotating arrow 2: represents the action of turning the screw counterclockwise or

buckling inward.
