SNR-VG-1000-8S VoIP Gateway User Manual
3
Port Name
Connector
Description
Power Jack
Power Jack
To connect DC 12V power supply
WAN/LAN Port
RJ45
to connect to the IP network over a DSL modem or Router or
a LAN switch
FXS Ports 0-7
RJ11
FXS ports to connect standard analog phone or FAX machine
or a PBX
1.5 Functions and Features
1.5.1 Protocol standard supported
• SIP V2.0 (RFC 3261,3262,3264)
•
SDP (RFC 2327)
• REFER (RFC 3515)
• RTP/RTCP (RFC 1889,1890)
•
STUN (RFC 3489)
• ARP/RARP (RFC 826/903)
• SNTP (RFC 2030)
•
DHCP/PPPoE
