SNR-VG-1000-8S VoIP Gateway User Manual
4
• TFTP/HTTP/HTTPS
• DNS/DNS SRV (RFC 1706/RFC 2782)
• VLAN 802.1P/802.1Q
1.5.2
Voice and Fax parameters
• G.711A/U law, G.723.1, G.729AB,iLBC,AMR
•
Comfortable Noise Generation (CNG)
•
Voice Activity Detection (VAD)
• Echo Cancellation (G.168)
•
Adaptive Dynamic Jitter Buffer
•
Voice and fax gain control
• Modem
•
T.38/Pass-through
•
DTMF Mode: Signal/RFC2833/INBAND
1.5.3 Supplementary service
• Call waiting
•
Call transfer
（
Blind transfer, Attend transfer,
）
•
Quick pick
• Call Forwarding Unconditional
• Call Forwarding on No Reply
• Hotline
• Call hold
•
DND
•
Three-way calling
• Voice mail
•
Direct IP Call
