10
• Cutting 0
- do not tilt the tool while cutting
- always move the tool in same direction as arrow on
tool head, in order to prevent the tool from being
pushed out of the cut in an uncontrolled manner
- do not apply pressure on the tool; let the speed of the
cutting disc do the work
- the working speed of the cutting disc depends on the
material to be cut
- do not brake cutting discs with side pressure
• Holding and guiding the tool
- always hold the tool rmly with both hands, so you will
have full control of the tool at all times
! whileworking,alwaysholdthetoolatthe
grey-colouredgriparea(s)!
- provide for a secure stance
- pay attention to the direction of rotation; always hold
the tool so, that sparks and grinding/cutting dust y
away from the body
- keep ventilation slots J 2 uncovered
MAINTENANCE/SERVICE
• Always keep tool and cord clean (especially ventilation
slots J 2)
! donotattempttocleanventilationslotsby
insertingpointedobjectsthroughopenings
! disconnecttheplugbeforecleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
• Donotdisposeofelectrictools,accessoriesand
packagingtogetherwithhouseholdwastematerial
(only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol @ will remind you of this when the need for
disposing occurs
DEClARAtION OF CONFORmItY
• We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
60745, EN 61000, EN 55014, in accordance with the
provisions of the directives 2004/108/EC, 2006/42/EC,
2011/65/EU
• Technicalfileat: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹ÊÁÂÆιÆ¼½ÊÇǾ¼½Æ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
Ĺ¾ÁÂÿʹ¹¾
ÈÈÊÇιÄ¹Æ¹¿½Ê
27.01.2014
NOISE/VIBRATION
• Measured in accordance with EN 60745 the sound
pressure level of this tool is 92 dB(A) and the sound
power level 103 dB(A) (standard deviation: 3 dB), and the
vibration ✱ (hand-arm method; uncertainty K = 1.5 m/s²)
✱ when surface grinding 7.4 m/s²
✱ when sanding 3.2 m/s²
! otherapplications(suchascutting-offorwire
brushing)mayhavedifferentvibrationvalues
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintained accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protectyourselfagainsttheeffectsofvibration
bymaintainingthetoolanditsaccessories,
keepingyourhandswarm,andorganizingyour
workpatterns
Meuleused’angle 9455
INtRODUCtION
• Cet outil sert au meulage, au tronçonnage et à l’ébarbage
de pièces en métal et en pierre sans utiliser de l’eau;
combiné avec des accessoires spéciques, cet outil peut
également servir au brossage et au ponçage
• Lesopérationsdecoupeavecdisquesàtronçonner
abrasifsnesontautoriséesquesiuneprotectionde
tronçonnage(disponibleenoptioncomme
accessoireSKIL2610399439)estutilisée
• Lisez et conservez ce manuel d’instruction 3
CARACtERIStIQUES tECHNIQUES 1
ELEMENTSDEL’OUTIL2
A Arbre
B Bride de serrage
C Clé
D Bouton de blocage de l’arbre
E Poignée auxiliaire
