20
- check for a 90° angle between blade and table with a
square
- if necessary, adjust the 90° blade alignment as follows:
1) loosen three-legged knob N
2) adjust screw N2 with a blade wrench 13 (not
standard included) and a 4 mm hex key (not
standard included)
3) re-check with square
• Checking/adjusting of 45° blade alignment ≤
! disconnect the plug
- rotate the saw table to the 0° position and lock in place
- lower the tool arm and lock in place
- loosen three-legged knob N
- swing the tool arm to 45°
- check for a 45° angle between blade and table with a
mitre square
- check that bevel indicator N1 is on the 45° mark
- if necessary, adjust the 45° blade alignment as follows:
1) adjust screw N3 with a blade wrench 13 (not
standard included) and a 4 mm hex key (not
standard included)
2) re-check with mitre square
• Checking/adjusting of 90° fence alignment ∞
! disconnect the plug
- rotate the saw table to the 0° position and lock in place
- lower the tool arm and lock in place
- check for a 90° angle between blade and fence L with
a square (ensure the square contacts the saw blade
body and not its teeth)
- if necessary, adjust the 90° fence alignment as follows:
1) loosen 4 hex screws L1
2) adjust fence until blade and fence have full contact
with the square
3) tighten 4 hex screws L1
• Cable storage §
APPLICATION ADVICE
• Special workpieces
- ensure that curved or round workpieces are especially
secured against slipping
- at the cutting line no gap may exist between the
workpiece and the fence or saw table
- if necessary, fabricate a special xture
• For working with oor mouldings illustration ≥ can be
used as reference
• Always face the good side of the workpiece down to
ensure minimum splintering
• Only use sharp saw blades of the correct type
- quality of cut improves by the number of teeth
- carbide tipped blades stay sharp up to 30 times longer
than ordinary blades
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially the
ventilation slots at the back-end of the motor housing)
! disconnect the plug before cleaning
• Clean saw blade immediately after use (especially from
resin and glue)
! the saw blade becomes very hot during use; do
not touch it before it has cooled down
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol • will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
• We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
61029, EN 61000, EN 55014, in accordance with the
provisions of the directives 2004/108/EC, 2006/42/EC,
2011/65/EU, 2009/125/EC (EU regulation 1194/2012)
• Technical file at: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹ÊÁÂÆιƼ½ÊÇǾ¼½Æ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
Ĺ¾ÁÂÿʹ¹¾
ÈÈÊÇιĹƹ¿½Ê
27.01.2014
NOISE/VIBRATION
• Measured in accordance with EN 61029 the sound
pressure level of this tool is 93 dB(A) and the sound
power level 106 dB(A) (standard deviation: 3 dB), and the
vibration < 2.5 m/s² (hand-arm method; uncertainty
K = 1.5 m/s²)
• The vibration emission level has been measured in
accordance with a standardised test given in EN 61029; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintained accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
