English-8

5. To keep the cables neatly organized, place them into the cable management system that is built into the stand.

Place the cables in the hooks fi rmly and evenly (Figure C.2 and Figure C.3).

6. Please check that you can still rotate, raise and lower the monitor screen when you have installed the cables.

Figure C.2 Figure C.3

USB Cable

Power Cord

DVI Cable

D-SUB Cable*

DisplayPort Cable

HDMI Cable*

*

7. Slide down the cable cover (Figure D.1).

8. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet.

NOTE: Please refer to Caution section of this manual for proper selection of AC power cord.

9. Turn on the monitor with the front power button (Figure E.1) and the computer.

10. No Touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup for most timings. For further

Raise and Lower the Monitor Screen

The monitor may be raised or lowered in either Portrait or Landscape mode.

To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1).

NOTE: Handle with care when raising or lowering the monitor screen.

Figure RL.1
