Viewsonic VA2403-mh [10/60] 2 the exterior of the monitor

2-2. The Exterior of the Monitor

A. Front B. Left and Right

C. Rear

41 3

1. Control panel

(Expanded in 3-1)

2. I/O port (input/output)

This area should include all I/O

connection options, as well as the

power input connector (Expanded

in 2-4)

3. Kensington security slot

(Expanded in 2-3 section G)

4. VESA wall mounting

This area on the back of the

monitor*. For the VESA wall

mounting installation steps, please

see 2-3 section F for additional

instructions.

5. Speaker
