Benq EW2440L [10/40] Ew2440
![Benq EW2440L [10/40] Ew2440](/views2/1983433/page10/bga.png)
10 How to assemble your monitor hardware
Orient and align the stand arm with the monitor, then
push them together until they click and lock into place.
Tighten the screw that fixes the stand to the monitor.
To secure or release a screw, a screwdriver or a coin is
required.
Carefully lift the monitor, turn it over and place it
upright on its stand on a flat even surface.
You should position the monitor and angle the screen to
minimize unwanted reflections from other light sources.
If the screen size is 24 inches, your monitor is an edge to
edge monitor and should be handled with care. Adjust the
screen angle by placing your hands on the top and on the
base of the monitor as illustrated. Excessive force on the
display is prohibited.
(EW2440)
1
2
-5
O
~ +20
O
-5
O
~ +20
O
-5
O
~ +20
O
-5
O
~ +20
O
